Frame
Orbea Gain Carbon OMR monocoque structure, Integrated Seat clamp with STVZO light, ICR cable routing, Thru Axle 12x142mm rear, thread M12x2 P1, Flat Mount disk, 700x35 max tire, BB386 EVO, Mahle X20 AMC plug.
Fork
Gain OMR carbon fork, 700x35 maximun tire, Flat Mount disk, Thru Axle 12x100mm, thread M12x2 P1.
Steerer Tube
FSA 1-1/2" Integrated Aluminum Cup.
Ebike Battery
Mahle iX350 36V 353Wh.
Range Extender
N/A.
Motor
Mahle motor hub X20, ALC.
Display
Mahle Pulsar One monochrome ANT+ LEV.
Charger
Mahle Active Charger up to 4A.
Remote
Mahle ONE Head Unit (BT/ANT+).
Remote2
Mahle Handlebar Dual eShifter.
Crankset
SRAM Force Dub Wide 40t.
Shifters
SRAM Force AXS.
Cassette
SRAM XG-1271 XPLR 10-44t 12-Speed.
Rear Derailleur
SRAM Force XPLR AXS 12s.
Chain
SRAM Force 12-Speed.
Handlebar
OC Gravel GR31, Reach 70, Drop 110.
Stem
OC Road Performance RP10, -8º.
Brakes
SRAM Force AXS.
Brakes Configuration
N/A.
Wheels
Alloy, Tubeless, 700c, 21c.
Tires
Pirelli Cinturato™ Gravel H 700x35c TLR.
Front Wheel Axle
Orbea Thru Axle 12x100mm M12x2 P1 Lite.
Rear Wheel Axle
Orbea Thru Axle 12x142mm M12x2 P1 Lite.
Seatpost
OC Performance XP10 Carbon, 27.2mm, Setback 0.
Saddle
Fizik Aliante R5.
Front Light
Rear position light, on saddle clamp, COB Led, On/Off, 12 Lumen. STVZO.
Handlebar Tape
Orbea Anti-Slippery/Shock Proof.
